Product Performance and Characteristics

---

Enhanced reverse osmosis membrane products use the latest upgrade of the membrane surface treatment process, changing the charge and smoothness of the membrane surface, greatly increasing the hydrophilicity of the membrane surface can effectively reduce the fouling of colloid, organic matter and other dirt, and greatly improve the cleaning and recovery performance of the membrane. At the same time, the special inlet channel structure is designed to further strengthen the anti-pollution ability of the membrane element and the cleaning and recovery performance. OP membrane element has the characteristics of high desalting rate and large flux, which is suitable for desalting of surface water, groundwater, municipal water and industrial water with salt content below 10000ppm.

Membrane Element Specification and Performance

---

Membrane Element Model	Stable Desalination Rate (%)	Minimum Desalination Rate (%)	Average Water Yield GPD (m³/d)	Effective Membrane Area (ft²)
OP5-10	99.75	99.5	11,500 (43.5)	400 (37.2)
OP5-10 LE	99.4	99.1	12,500 (47.3)	400 (37.2)
HC70	99.75	99.6	8,800 (33.3)	400 (37.2)
HC80	99.55	99.2	9,100 (34.4)	440 (41.0)
HP120	99.75	99.5	7,400 (28.0)	330 (30.6)

Test Conditions

---

Test pressure ———————————————— 225 psi (OP5-10); 600 psi (HC80); 800 psi (HC70, HP120)
Test solution temperature ———————————– 25°C
Test solution concentration (NaCl) ————————– 2000 ppm (OP5-10); 32000 ppm (HC70, HC80, HP120)
PH value of test solution ————————————- 7.0-7.5
Recovery rate of single membrane element ——————- 15% (HC); (HP)

Limit Service Conditions

---

Maximum operation pressure ——————————– 600 psi (OP5-10); 1305 psi (HC); 1740 psi (HP120)
Maximum inlet flow —————————————— 75 gpm (17 m³/h) (8040), 16 gpm (3.6 m³/h) (4040)
Maximum inlet temperature ——————————— 45°C
Maximum inlet SDI₅ ——————————————- 5
Free Chlorine Concentration in Inlet ———————— <0.1 ppm
PH range of inlet during continuous operation ————- 2-11
PH range of inlet during chemical cleaning —————– 1-13
Maximum pressure drop of single membrane element —– 15 psi (0.1 Mpa)

Dimensions of Membrane Elements

---

All units shown in the diagram are in millimeters (inches)

Note : The dimensions of membrane elements shown in the above figure are marked with tolerances.

Important Information

---

Before use or storage, review these additional resources for important information:
Ovay Usage Guidelines
System Operation: Initial Start-Up
Contact an Ovay representative for reasonable technical support.

General Information

---

Keep elements moist at all times after initial wetting
Membrane elements must be immersed in a preservative solution to inhibit biological growth
during a long-term outage. Rinse out the preservative before reuse.
Maximum pressure drop across an entire pressure vessel (housing) is 15 ps（i 0.1 Mpa）
Avoid static permeate-side back pressure at all times

The Limited Warranty will be null and void if operating limits and guidelines given in this Product Information Bulletin are not strictly followed and the customer is fully responsible for the effects of chemicals that are incompatible with the elements.

Notice
The use of this product in medical-related contexts does not necessarily guarantee removal of cysts and pathogens or thorough disinfection of oxygen and system. The performance depends on the complete system design, operation, maintenance, and regular replacement of the system.

Notice

Ovay accepts no responsibility for results obtained by the application of this information or the safety or suitability of Ovay’s products, either alone or in combination with other products. Users are advised to make their own tests to determine the safety and suitability of each product combination for their own purposes and ensure that Customer’s workplace and disposal practices are in compliance with applicable laws and other governmental enactments. All data may change without prior notice, due to technical modifications or production changes. Ovay assumes no obligation or liability for the information in this document.

NO WARRANTIES ARE GIVEN; ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED
